Grain Intake Systems

High-rate grain reception with surge capacity and dust containment from the first point of contact.

Receiving hoppers, grizzly grids, and connecting conveying for accepting grain from truck, tractor trailer, or rail at high intake rates. Designed with surge capacity and dust containment from the first point of reception.

Locally Manufactured
Sourced Specialised Equipment
Client-Preferred Brands Incorporated
Project Gallery

Built for the real world

4 photos
01 / 04
Featured image

Overview

A grain intake system is the first link in any grain handling facility and sets the maximum throughput capacity for the entire plant. Facet Engineering designs intake systems for truck tip, bottom-discharge trailer, and rail wagon unloading. The receiving hopper is sized to accept a full vehicle load without manual assistance, and the grizzly grid prevents large foreign objects from entering the conveying system. An integral pre-cleaner or scalper screen removes gross contaminants before the grain reaches the main transfer conveyors. Dust suppression from the first point of impact is included in all Facet intake designs as standard.

Grain intake capacities and custom sizes

Grain intake systems are custom-built to your required size and intake capacity, rather than being restricted to a fixed standard capacity. Specify your target intake rate in tonnes per hour (t/h), vehicle type and receiving-hopper requirement so the hopper and connecting conveyors can be designed together.

Truck-tip, bottom-discharge trailer and rail-wagon intake configurations are available. The final throughput is confirmed against the grain, bulk density, unloading arrangement and downstream plant capacity.

Key Features

Hopper sized for full vehicle load without manual assistance
Grizzly grid to exclude oversized foreign material
Integral scalper screen option for gross pre-cleaning
Dust suppression at all impact and transfer points

Typical Applications

Grain silo intake from truck and trailer
Rail wagon unloading facilities
Processing plant raw material reception
Co-operative and merchant grain intake

Equipment questions and answers

What grain intake capacities does Facet Engineering offer?

Facet Engineering grain intake systems are custom-built to the required intake capacity rather than restricted to one fixed standard rate. Specify the required throughput in tonnes per hour (t/h); the final capacity is confirmed for the material and plant arrangement.

Which grain unloading arrangements can be supplied?

Facet Engineering supplies intake configurations for truck tipping, bottom-discharge trailers and rail wagons. Receiving hoppers and connecting conveyors are sized together to suit the vehicle and required intake rate.

What information is needed to specify a grain intake system?

Provide the grain, bulk density, required intake rate in t/h, vehicle type, unloading arrangement and receiving-hopper requirement. The downstream plant capacity must also be considered when confirming the system throughput.

Notes

All intake systems are engineered to the specific vehicle type and throughput requirement.

Dust extraction integration is available for fully enclosed plant environments.

Specifications

Intake CapacityCustom-designed to required throughput (t/h)
Hopper CapacityMatched to vehicle size
Unloading ModeTruck tip, bottom-discharge, rail
Pre-cleaningScalper screen optional
Dust ControlSuppression at all impact points
